SCMS5D20-R47

Signal Transformer
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Active 2009 Tape & Reel (TR) fixed air core inductor -40C~125C 100kHz 22mOhm Max 470nH
PDF
/
Inventory: 8359
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 5.207mm
Length 5.207mm
Height Seated (Max) 0.083 2.10mm

Technical

Current - Saturation 4A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 22mOhm Max
Test Frequency 100kHz
Inductance 470nH
Current Rating 3.1A
Shielding Shielded
Current Rating (Amps) 3.1A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Series SCMS5D20
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
