PL9301

PulseR
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Active Tube Surface Mount fixed air core inductor -55C~130C 5.5mOhm Max 680nH ±25%
PDF
/
Inventory: 2877
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mounting Type Surface Mount
Package / Case Nonstandard

Technical

Operating Temperature -55°C~130°C
Packaging Tube
Series PL93XX
Size / Dimension 0.410Lx0.410W 10.41mmx10.41mm
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 7.6A
Shielding Shielded
Depth 10.41mm
Inductance 680nH
DC Resistance (DCR) 5.5mOhm Max
Max DC Current 7.6A
Current - Saturation 10A

Dimensions

Height 4mm
Height Seated (Max) 0.157 4.00mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
