PL9227
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Active Tube Surface Mount fixed air core inductor -55C~130C 1.087Ohm Max 390muH ±20%
PDF
/
Inventory: 2861
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.201 5.10mm
Height 5.1mm
Technical
Current - Saturation 660mA
Max DC Current 580mA
DC Resistance (DCR) 1.087Ohm Max
Inductance 390μH
Depth 10.5mm
Shielding Shielded
Current Rating (Amps) 580mA
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Series PL92XX
Packaging Tube
Operating Temperature -55°C~130°C
Physical
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
