PL9222
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Active 2007 Tube Fixed Inductor -55C~130C 456mOhm Max 150muH ±20%
PDF
/
Inventory: 7262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -55°C~130°C
Packaging Tube
Published 2007
Series PL92XX
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 1.02A
Shielding Shielded
Depth 10.5mm
Inductance 150μH
DC Resistance (DCR) 456mOhm Max
Max DC Current 1.02A
Current - Saturation 1.05A
Dimensions
Height 5.1mm
Height Seated (Max) 0.201 5.10mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
