PL9209T

PulseR
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Active Tape & Reel (TR) Surface Mount fixed air core inductor -55C~130C 37mOhm Max 12muH ±20%
PDF
/
Inventory: 3591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.201 5.10mm
Height 5.1mm

Technical

Current - Saturation 3.7A
Max DC Current 3.3A
DC Resistance (DCR) 37mOhm Max
Inductance 12μH
Depth 10.5mm
Shielding Shielded
Current Rating (Amps) 3.3A
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Series PL92XX
Packaging Tape & Reel (TR)
Operating Temperature -55°C~130°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
