PG0871.222NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PG0871NL Nonstandard 0.299Lx0.291W 7.60mmx7.40mm 2.2muH
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9624
≥1 USD $1.9624
≥10 USD $1.66584
≥100 USD $1.535072
≥500 USD $1.37192
≥1000 USD $1.143208
≥3000 USD $1.11056
Inventory: 1366
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series PG0871NL
Size / Dimension 0.299Lx0.291W 7.60mmx7.40mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Current Rating (Amps) 9.5A
Shielding Shielded
Number of Functions 1
Inductance 2.2μH
Test Frequency 0.1MHz
DC Resistance (DCR) 7.6mOhm
Inductor Application POWER INDUCTOR
Inductance Frequency - Test 100kHz
Current - Saturation 12A
Rated Current-Max 9.5A
Special Feature DCR IS MEASURED AT 8% TOLERANCE
Dimensions
Height Seated (Max) 0.252 6.40mm
Compliance
RoHS Status RoHS Compliant
