PG0063.103NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Active ONE SURFACE Fixed Inductor -40C~130C 100kHz 150mOhm Max 10muH
PDF
/
Inventory: 2405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series PG0063
Size / Dimension 0.244Lx0.244W 6.20mmx6.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 1.2A
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 150mOhm Max
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Rated Current-Max 1.9A
Dimensions
Height Seated (Max) 0.098 2.50mm
Compliance
RoHS Status RoHS Compliant
