PF0560.104NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PF0560NL Nonstandard 0.409Lx0.406W 10.40mmx10.30mm 100muH
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.21352
≥100 USD $1.118656
≥500 USD $0.999504
≥1000 USD $0.83292
≥3000 USD $0.809107
Inventory: 700
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.157 4.00mm
Height 4mm
Technical
DC Current 1.25A
Case/Size Code 4141
Current - Saturation 1.35A
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 6.6MHz
Max DC Current 1.25A
DC Resistance (DCR) 304mOhm Max
Test Frequency 100kHz
Inductance 100μH
Military Standard Not
Current Rating 1.25A
Depth 10.3mm
Number of Functions 1
Shielding YES
Packing Method TR
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±25%
Size / Dimension 0.409Lx0.406W 10.40mmx10.30mm
Series PF0560NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
