PA5003.102NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PA5003.XXXNLT Nonstandard 0.217Lx0.209W 5.50mmx5.30mm 1muH
PDF
/
Buying Options
Total Price: USD $1.57
Unit Price: USD $1.5664
≥1 USD $1.5664
≥10 USD $1.33232
≥100 USD $1.228128
≥500 USD $1.097536
≥1000 USD $0.914584
≥3000 USD $0.888448
Inventory: 406
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.122 3.10mm
Technical
Current - Saturation 16.5A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 7.6mOhm Max
Inductance 1μH
Shielding Shielded
Current Rating (Amps) 12.2A
Type Molded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.217Lx0.209W 5.50mmx5.30mm
Series PA5003.XXXNLT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
