PA4343.153NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PA4343.XXXNLT Nonstandard 0.551Lx0.504W 14.00mmx12.80mm 15muH
PDF
/
Buying Options
Total Price: USD $1.57
Unit Price: USD $1.5664
≥1 USD $1.5664
≥10 USD $1.33232
≥100 USD $1.228128
≥500 USD $1.097536
≥1000 USD $0.914584
≥3000 USD $0.888448
Inventory: 1079
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.256 6.50mm
Technical
Rated Current-Max 9A
Current - Saturation 12.5A
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 28mOhm Max
Test Frequency 0.1MHz
Inductance 15μH
Number of Functions 1
Shielding YES
Current Rating (Amps) 9A
HTS Code 8504.50.80.00
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.551Lx0.504W 14.00mmx12.80mm
Series PA4343.XXXNLT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
