PA4303.223NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Active 8504.50.80.00 fixed air core inductor -40C~125C 1kHz 75mOhm Max 22muH
PDF
/
Buying Options
Total Price: USD $1.35
Unit Price: USD $1.3464
≥1 USD $1.3464
≥10 USD $1.14224
≥100 USD $1.052832
≥500 USD $0.94072
≥1000 USD $0.783904
≥3000 USD $0.761517
Inventory: 1102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series PA4303.XXXNLT
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding Shielded
Current Rating 2.5A
Inductance 22μH
Test Frequency 1kHz
DC Resistance (DCR) 75mOhm Max
Inductance Frequency - Test 1kHz
Dimensions
Height Seated (Max) 0.197 5.00mm
Compliance
RoHS Status RoHS Compliant
