PA1393.102NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PA1393NL Nonstandard 0.780Lx0.770W 19.81mmx19.56mm 1muH
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4903
≥1 USD $3.4903
≥10 USD $2.86425
≥100 USD $2.77495
≥500 USD $2.68565
≥1000 USD $2.5954
Inventory: 1102
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.290 7.37mm
Height 7.366mm
Technical
DC Current 42A
Case/Size Code 7877
Current - Saturation 68A
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 42A
DC Resistance (DCR) 1.43mOhm Max
Inductance 1μH
Military Standard Not
Current Rating 42A
Construction Rectangular
Depth 19.56mm
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Type Planar
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±15%
Size / Dimension 0.780Lx0.770W 19.81mmx19.56mm
Series PA1393NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C
Physical
Core Material AMORPHOUS MAGNETIC
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
