P1172.683NLT image
Favorite
P1172.683NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description P1172NL Nonstandard 0.482Lx0.482W 12.24mmx12.24mm 68muH
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.319049
≥1 USD $1.319049
≥10 USD $1.244387
≥100 USD $1.173952
≥500 USD $1.107501
≥1000 USD $1.044813
Inventory: 1237
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material AMORPHOUS MAGNETIC

Technical

Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series P1172NL
Size / Dimension 0.482Lx0.482W 12.24mmx12.24mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Resistance 135mOhm
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 12.24mm
Construction Chip
Current Rating 2.1A
Military Standard Not
Inductance 68μH
Test Frequency 100kHz
DC Resistance (DCR) 135mOhm Max
Max DC Current 2.1A
Frequency - Self Resonant 6MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 4848
DC Current 2.1A

Dimensions

Height 8.001mm
Height Seated (Max) 0.315 8.00mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
