P1167.393NLT image
Favorite
P1167.393NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description P1167NL Nonstandard 0.297Lx0.297W 7.54mmx7.54mm 39muH
PDF
/
Inventory: 7521
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.177 4.50mm
Height 4.5mm

Technical

Case/Size Code 3030
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 12MHz
Max DC Current 1A
DC Resistance (DCR) 200mOhm Max
Test Frequency 100kHz
Inductance 39μH
Current Rating 1A
Construction Chip
Depth 7.54mm
Number of Functions 1
Shielding YES
Packing Method TR
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.297Lx0.297W 7.54mmx7.54mm
Series P1167NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C

Physical

Core Material AMORPHOUS MAGNETIC
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
