P0770.472NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
P0770NL Nonstandard 0.260Lx0.175W 6.60mmx4.45mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.79552
≥100 USD $0.72336
≥500 USD $0.679888
≥1000 USD $0.564168
≥3000 USD $0.520749
Inventory: 634
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.115 2.92mm
Technical
Special Feature INDUCTANCE MEASURED WITH PEAK RATED CURRENT
Rated Current-Max 1.5A
Case/Size Code 2618
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 90mOhm Max
Test Frequency 0.1MHz
Inductance 4.7μH
Number of Functions 1
Shielding Unshielded
Packing Method TR
Current Rating (Amps) 1.5A
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Series P0770NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C
Physical
Core Material Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape ONE SURFACE
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
