P0762.473NLT image
Favorite
P0762.473NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Wirewound Active ONE SURFACE fixed air core inductor -40C~130C 100kHz 390mOhm Max 47muH
PDF
/
Inventory: 5843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Series P0762NL
Size / Dimension 0.510Lx0.370W 12.95mmx9.40mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Depth 9.4mm
Current Rating 800mA
Inductance 47μH
Test Frequency 100kHz
DC Resistance (DCR) 390mOhm Max
Max DC Current 1A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 1A
Case/Size Code 5137
Special Feature INDUCTANCE MEASURED WITH PEAK DC CURRENT

Dimensions

Height 2.9972mm
Height Seated (Max) 0.118 3.00mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
