RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND Fixed Inductor -40C~150C 100kHz 44.44mOhm Max 10muH
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
≥10 USD $0.71544
≥100 USD $0.650496
≥500 USD $0.611248
≥1000 USD $0.507232
≥3000 USD $0.46823
Inventory: 276
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 20 Weeks

Physical

Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Metal Composite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -40°C~150°C
Packaging Tape & Reel (TR)
Series PCC-M0648M-LE
Size / Dimension 0.252Lx0.236W 6.40mmx6.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Current Rating (Amps) 5.2A
Packing Method TR, 13 Inch
Shielding Shielded
Number of Functions 1
Construction Rectangular
Inductance 10μH
Test Frequency 0.1MHz
DC Resistance (DCR) 44.44mOhm Max
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 8.1A
Case/Size Code 2524
Rated Current-Max 5.2A
Special Feature DC RESISTANCE MEASURED AT: 10%

Dimensions

Height Seated (Max) 0.189 4.80mm

Compliance

RoHS Status ROHS3 Compliant
Ratings AEC-Q200
