ELL-5PR6R8N
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
R Nonstandard 0.197Lx0.197W 5.00mmx5.00mm 6.8muH
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.784811
≥1 USD $0.784811
≥10 USD $0.740391
≥100 USD $0.698485
≥500 USD $0.658945
≥1000 USD $0.621644
Inventory: 1092
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2011
Series R
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Tolerance ±30%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 85mOhm
HTS Code 8504.50.80.00
Shielding Shielded
Depth 5.2mm
Current Rating 1.4A
Case Code (Metric) 3225
Case Code (Imperial) 1210
Lead Pitch 1.8mm
Inductance 6.8μH
Test Frequency 100kHz
DC Resistance (DCR) 85mOhm
Current 1.4A
Max DC Current 1.7A
Inductance Tolerance 30%
RMS Current (Irms) 1.25A
Series Resistance 85mOhm
Dimensions
Height 1.85mm
Height Seated (Max) 0.079 2.00mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
