ELC-3GN220M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
N Nonstandard 0.126Lx0.126W 3.20mmx3.20mm 22muH
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.44088
≥100 USD $0.403744
≥500 USD $0.367136
≥1000 USD $0.326656
≥3000 USD $0.308352
Inventory: 1114
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.059 1.50mm
Height 1.55mm
Technical
DC Current 330mA
Case/Size Code 1212
Max DC Current 330mA
Current 280mA
DC Resistance (DCR) 950mOhm
Test Frequency 100kHz
Inductance 22μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Military Standard Not
Current Rating 330mA
Depth 3.5mm
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Tolerance ±20%
Size / Dimension 0.126Lx0.126W 3.20mmx3.20mm
Series N
Published 2005
Packaging Tape & Reel (TR)
Physical
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
