ELC-3FN100M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
N Nonstandard 0.126Lx0.126W 3.20mmx3.20mm 10muH
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.42152
≥100 USD $0.386144
≥500 USD $0.35112
≥1000 USD $0.312488
≥3000 USD $0.294906
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Published 2005
Series N
Size / Dimension 0.126Lx0.126W 3.20mmx3.20mm
Tolerance ±20%
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Depth 3.5mm
Current Rating 530mA
Military Standard Not
Case Code (Metric) 3225
Case Code (Imperial) 1210
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 430mOhm
Current 260mA
Max DC Current 530mA
Case/Size Code 1212
DC Current 530mA
Dimensions
Height 1.2mm
Height Seated (Max) 0.047 1.20mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
