ELC-10E221L
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
10E Radial Vertical Cylinder 0.394Dia 10.00mm 220muH
PDF
/
Inventory: 1370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.512 13.00mm
Height 13mm
Diameter 10mm
Technical
Special Feature DC RESISTANCE IS MEASURED AT 20% TOLERANCE
RMS Current (Irms) 640mA
Inductance Tolerance 10%
Lead/Base Style Radial
Inductor Application POWER INDUCTOR
Max DC Current 640mA
Current 370mA
DC Resistance (DCR) 410mOhm
Test Frequency 10kHz
Inductance 220μH
Lead Diameter 700 μm
Lead Spacing 7mm
Operating Temperature (Min) -20°C
Operating Temperature (Max) 105°C
Lead Pitch 5mm
Current Rating 640mA
Construction Cylindrical
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Tolerance ±10%
Size / Dimension 0.394Dia 10.00mm
Series 10E
Packaging Bulk
Physical
Core Material Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
