S34042
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 330UH 1A 110 MOHM SMD
PDF
/
Inventory: 7518
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Packaging Bulk
Published 2003
Size / Dimension 1.125Lx0.740W 28.58mmx18.80mm
Part Status Active
Current Rating (Amps) 1A
Shielding Unshielded
Current Rating 1A
Inductance 330μH
Test Frequency 10kHz
DC Resistance (DCR) 110mOhm Max
Inductance Frequency - Test 10kHz
Dimensions
Height Seated (Max) 0.450 11.43mm
Length 28.575mm
Width 18.796mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
