49220SC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard, 4 Lead
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4900S Nonstandard 4Lead 0.480Lx0.480W 12.20mmx12.20mm 22muH
PDF
/
Inventory: 2280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard, 4 Lead
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 4900S
Size / Dimension 0.480Lx0.480W 12.20mmx12.20mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 12.5mm
Current Rating 3.1A
Inductance 22μH
Test Frequency 10kHz
DC Resistance (DCR) 42mOhm Max
Max DC Current 3.1A
Frequency - Self Resonant 12MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 46 @ 1MHz
Dimensions
Height 8mm
Height Seated (Max) 0.315 8.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
