40220C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4000 Nonstandard 0.560Lx0.555W 14.22mmx14.10mm 22muH
PDF
/
Inventory: 5581
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.345 8.76mm
Height 8.76mm
Technical
Terminal Placement DUAL ENDED
Inductor Application DC-DC CONVERTER
Max DC Current 2.1A
DC Resistance (DCR) 35mOhm Max
Test Frequency 10kHz
Inductance 22μH
Current Rating 2.1A
Depth 14.1mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Toroidal
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.560Lx0.555W 14.22mmx14.10mm
Series 4000
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
