26S3R3C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
2600 Nonstandard 0.496Lx0.181W 12.60mmx4.60mm 3.3muH
PDF
/
Inventory: 4506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 2600
Size / Dimension 0.496Lx0.181W 12.60mmx4.60mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding Shielded
Number of Functions 1
Depth 11.6mm
Current Rating 4.6A
Inductance 3.3μH
Test Frequency 1kHz
DC Resistance (DCR) 33mOhm Max
Max DC Current 4.6A
Frequency - Self Resonant 46MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Dimensions
Height 5.4mm
Height Seated (Max) 0.232 5.90mm
Compliance
RoHS Status RoHS Compliant
