1422604C
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1400 Radial Vertical Cylinder 1.173Dia 29.80mm 22mH
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5552
≥1 USD $3.5552
≥10 USD $3.5464
≥100 USD $3.5112
≥500 USD $3.4672
≥1000 USD $3.3792
≥3000 USD $3.2208
Inventory: 40
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series 1400
Size / Dimension 1.173Dia 29.80mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 31.3mm
Construction Bobbin Type
Current Rating 400mA
Military Standard Not
Lead Pitch 28.3mm
Lead Length 10mm
Inductance 22mH
Test Frequency 1kHz
DC Resistance (DCR) 6.962Ohm Max
Max DC Current 400mA
Frequency - Self Resonant 200kHz
Inductor Application POWER INDUCTOR
Q @ Freq 30 @ 50kHz
Lead/Base Style Radial
Quality Factor-Min (at L-nom) 30
Q Factor 30
DC Current 400mA
Special Feature Q MEASURED AT 0.05 MHZ
Dimensions
Diameter 30.5mm
Height 23.3mm
Height Seated (Max) 0.917 23.30mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
