MDH7045C-470MA=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Not For New Designs WRAPAROUND fixed air core inductor -55C~150C 100kHz 130mOhm 47muH
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.3288
≥1 USD $1.3288
≥10 USD $1.122
≥100 USD $1.019744
≥500 USD $0.958496
≥1000 USD $0.795344
≥3000 USD $0.734202
Inventory: 3265
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.189 4.80mm
Technical
Rated Current-Max 1.1A
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 130mOhm
Test Frequency 0.1MHz
Inductance 47μH
Number of Functions 1
Shielding Unshielded
Current Rating (Amps) 1.1A
Type Wirewound
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Tolerance ±20%
Size / Dimension 0.291Lx0.276W 7.40mmx7.00mm
Series MDH7045C
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 3 weeks ago)
