MBH7045C-221MA=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
MBH7045C Nonstandard 0.283Lx0.283W 7.20mmx7.20mm 220muH
PDF
/
Inventory: 987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.189 4.80mm
Technical
Rated Current-Max 0.65A
Current - Saturation 450mA
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 624mOhm Max
Test Frequency 100kHz
Inductance 220μH
Operating Temperature (Min) -40°C
Operating Temperature (Max) 150°C
Current Rating 650mA
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Tolerance ±20%
Size / Dimension 0.283Lx0.283W 7.20mmx7.20mm
Series MBH7045C
Packaging Tape & Reel (TR)
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
