LQW2UAS22NF00L
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 22NH 1A 120 MOHM
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.36138
≥1 USD $0.36138
≥10 USD $0.340929
≥100 USD $0.321628
≥500 USD $0.303419
≥1000 USD $0.286247
Inventory: 8512
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Supplier Device Package 1008 (2520 Metric)
Material - Core Non-Magnetic
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series LQW2
Size / Dimension 0.103Lx0.096W 2.62mmx2.45mm
Tolerance ±1%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 1A
Shielding Unshielded
Inductance 22nH
DC Resistance (DCR) 120mOhm Max
Frequency - Self Resonant 2.4GHz
Q @ Freq 55 @ 350MHz
Inductance Frequency - Test 50MHz
Dimensions
Height Seated (Max) 0.080 2.03mm
Compliance
RoHS Status ROHS3 Compliant
