LQW18AN27NG1ZD
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active ONE SURFACE fixed air core inductor -55C~125C 2.8GHz 116mOhm Max 27nH
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.207431
≥1 USD $0.207431
≥10 USD $0.195689
≥100 USD $0.184614
≥500 USD $0.174163
≥1000 USD $0.164305
Inventory: 1201
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.039 1.00mm
Technical
Special Feature Q MEASURED AT 250 MHZ
Rated Current-Max 0.59A
Inductance Frequency - Test 100MHz
Quality Factor-Min (at L-nom) 42
Q @ Freq 42 @ 250MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 2.8GHz
DC Resistance (DCR) 116mOhm Max
Test Frequency 100MHz
Inductance 27nH
Number of Functions 1
Shielding NO
Current Rating (Amps) 590mA
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Type Wirewound
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±2%
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Series LQW18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Air
Terminal Shape ONE SURFACE
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 7 Weeks
