LQH44NN331K03L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LQH44 Nonstandard 0.157Lx0.157W 4.00mmx4.00mm 330muH
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.57401
≥1 USD $0.57401
≥10 USD $0.541519
≥100 USD $0.510865
≥500 USD $0.481953
≥1000 USD $0.454669
Inventory: 3532
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series LQH44
Size / Dimension 0.157Lx0.157W 4.00mmx4.00mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 180mA
Inductance 330μH
Test Frequency 1kHz
DC Resistance (DCR) 2.28Ohm Max
Max DC Current 180mA
Frequency - Self Resonant 3MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Dimensions
Height 4.3mm
Height Seated (Max) 0.177 4.50mm
Compliance
RoHS Status ROHS3 Compliant
