LQH32PB4R7NN0L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.150742
≥1 USD $0.150742
≥10 USD $0.142214
≥100 USD $0.134158
≥500 USD $0.126566
≥1000 USD $0.119395
Inventory: 1226
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series LQH32
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method Tape, Embossed
Shielding YES
Number of Functions 1
Current Rating 1A
Inductance 4.7μH
Test Frequency 1MHz
DC Resistance (DCR) 180mOhm
Frequency - Self Resonant 40MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 1MHz
Case/Size Code 1210
Rated Current-Max 1A
Dimensions
Height Seated (Max) 0.067 1.70mm
Compliance
RoHS Status ROHS3 Compliant
