LQH32MN270J23L

Murata Electronics
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 27muH
PDF
/
Buying Options
Total Price: USD $3.02
Unit Price: USD $3.015904
≥1 USD $3.015904
≥10 USD $2.845198
≥100 USD $2.68414
≥500 USD $2.532213
≥1000 USD $2.388879
Inventory: 7888
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.087 2.20mm
Height 2mm

Technical

DC Current 125mA
Q Factor 35
Quality Factor-Min (at L-nom) 35
Q @ Freq 35 @ 1MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Max DC Current 125mA
DC Resistance (DCR) 3.1Ohm Max
Test Frequency 1MHz
Inductance 27μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Military Standard Not
Frequency 13MHz
Current Rating 125mA
Depth 2.7mm
Number of Functions 1
Shielding NO
Packing Method TR, Embossed Plastic, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±5%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series LQH32
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 59.987591mg
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
