LQH32CN471K23L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 470muH
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.708
≥1 USD $0.708
≥10 USD $0.66792
≥100 USD $0.63011
≥500 USD $0.59445
≥1000 USD $0.5608
≥3000 USD $0.52906
Inventory: 20005
Minimum: 1
-
+
Technical Details
Technical
Number of Functions 1
Depth 2.7mm
Current Rating 60mA
Frequency 5MHz
Military Standard Not
Case Code (Metric) 3225
Case Code (Imperial) 1210
Inductance 470μH
Test Frequency 1kHz
DC Resistance (DCR) 24.7Ohm Max
Max DC Current 60mA
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q Factor 40
Inductance Tolerance 10%
DC Current 60mA
Shielding NO
Packing Method Tape, Embossed
HTS Code 8504.50.80.00
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 19Ohm
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Tolerance ±10%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series LQH32
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height 2mm
Height Seated (Max) 0.067 1.70mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 59.987591mg
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
