DFEH10040D-100M=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DFEH10040D Nonstandard 0.429Lx0.394W 10.90mmx10.00mm 10muH
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.582402
≥1 USD $1.582402
≥10 USD $1.492835
≥100 USD $1.40834
≥500 USD $1.328618
≥1000 USD $1.253422
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.157 4.00mm
Technical
Current - Saturation 7.3A
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance Frequency - Test 100MHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 33mOhm Max
Test Frequency 100MHz
Inductance 10μH
Current Rating 5.7A
Number of Functions 1
Shielding YES
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Tolerance ±20%
Size / Dimension 0.429Lx0.394W 10.90mmx10.00mm
Series DFEH10040D
Packaging Tape & Reel (TR)
Operating Temperature -40°C~155°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron Powder
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 4 weeks ago)
