DD1217AS-H-3R3N=P3
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DEM8045C Nonstandard 0.315Lx0.315W 8.00mmx8.00mm 3.3muH
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.722761
≥1 USD $0.722761
≥10 USD $0.681845
≥100 USD $0.643255
≥500 USD $0.606845
≥1000 USD $0.572495
Inventory: 1096
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.177 4.50mm
Technical
Inductance Tolerance 30%
Current - Saturation 10.3A
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 14.4mOhm Max
Test Frequency 100kHz
Inductance 3.3μH
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Reference Standard AEC-Q200
Current Rating 6.8A
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Tolerance ±30%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series DEM8045C
Packaging Tape & Reel (TR)
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
