1248AS-H-4R7N=P3
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description
DEM8040C 2-SMD 0.315Lx0.315W 8.00mmx8.00mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.66528
≥100 USD $0.605088
≥500 USD $0.568656
≥1000 USD $0.471944
≥3000 USD $0.4356
Inventory: 657
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.157 4.00mm
Technical
Current - Saturation 6.2A
Terminal Placement DUAL ENDED
Max DC Current 5.3A
DC Resistance (DCR) 22.8mOhm Max
Test Frequency 100kHz
Inductance 4.7μH
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Current Rating 5.3A
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series DEM8040C
Packaging Tape & Reel (TR)
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 13 Weeks
