MCNL453232-5R6K

Multicomp
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 33MHz 1.1Ohm 5.6muH 1.7mm
PDF
/
Inventory: 5566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 3.2mm

Technical

Inductance-Nom (L) 5.6 μH
Inductance Tolerance 10%
DC Resistance (DCR) - Parallel 1.1Ohm
Case/Size Code 1713
Q Factor 50
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 50
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 33MHz
Max DC Current 300mA
Test Frequency 7.96MHz
Inductance 5.6 μH
Lead Pitch 1.7mm
Case Code (Imperial) 1812
Case Code (Metric) 4532
Number of Functions 1
Shielding NO
Number of Terminations 2
Packaging Cut Tape

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Terminal Shape WRAPAROUND
Mount Surface Mount

Alternative Model
