L1210R100MDWIT
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
L-DWI 1210 (3225Metric) 0.126Lx0.098W 3.20mmx2.50mm 10muH
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.365944
≥1 USD $0.365944
≥10 USD $0.345227
≥100 USD $0.325683
≥500 USD $0.30726
≥1000 USD $0.289862
Inventory: 2223
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Series L-DWI
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Composition Ceramic, Wirewound
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Number of Functions 1
Depth 2.7mm
Current Rating 900mA
Military Standard Not
Case Code (Metric) 3225
Case Code (Imperial) 1210
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 133mOhm
Max DC Current 900mA
Frequency - Self Resonant 23MHz
Inductor Application HIGH CURRENT INDUCTOR
Terminal Placement DUAL ENDED
Inductance Tolerance 20%
DC Current 900mA
Special Feature DCR IS MEASURED AT 30% TOLERANCE
Dimensions
Height 2.5mm
Height Seated (Max) 0.106 2.70mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
