1539M08 image
Favorite
1539M08 image
Favorite
RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description 1539 Radial Vertical Cylinder 0.830Dia 21.08mm 1mH
PDF
/
Buying Options
Total Price: USD $11.91
Unit Price: USD $11.9064
≥1 USD $11.9064
≥10 USD $11.21032
≥100 USD $10.922648
Inventory: 28
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.910 23.11mm
Height 23.114mm
Diameter 21.1mm

Technical

Self Resonant Frequency 700kHz
Inductor Application RF INDUCTOR
Max DC Current 1.3A
DC Resistance (DCR) 801mOhm Max
Test Frequency 1kHz
Inductance 1mH
Lead Spacing 0.66mm
Lead Length 25.4mm
Current Rating 1.3A
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±10%
Size / Dimension 0.830Dia 21.08mm
Series 1539
Published 2000
Packaging Bulk

Physical

Shape/Size Description CYLINDRICAL PACKAGE
Material - Core Ferrite
Weight 99.999994g
Terminal Shape PRINTED WIRING PIN
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 4 Weeks
