SMRF3013-103KLF

Gowanda Electronics
RoHS
/
Package 3013
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 125C 13MHz 8Ohm 100muH
PDF
/
Inventory: 9223
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 2.79mm
Length 7.62mm
Height 1.91mm

Technical

Inductance-Nom (L) 100 μH
DC Resistance (DCR) - Parallel 8Ohm
Q Factor 30
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 50
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 13MHz
Max DC Current 159mA
Test Frequency 2.5MHz
Inductance 100 μH
Number of Functions 1
Shielding Unshielded
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 8Ohm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e2
Tolerance 10%

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 3013
