SMP8527-222K
RoHS
/
Package 8527
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant WRAPAROUND DUAL ENDED fixed air core inductor 125C 0.001MHz 59mOhm 22muH
PDF
/
Inventory: 3847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Inductance-Nom (L) 22 μH
DC Resistance (DCR) - Parallel 59mOhm
Case/Size Code 8627
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 2.88A
Test Frequency 0.001MHz
Inductance 22 μH
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Reach Compliance Code not_compliant
Construction Chip
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 59mOhm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code no
JESD-609 Code e0
Tolerance 10%
Physical
Core Material NICKEL-ZINC FERRITE
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 8527
