B82559A353A20
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Tape & Reel (TR) Ferrite Surface Mount fixed air core inductor 150C 2MHz 7mOhm 35muH
PDF
/
Inventory: 5455
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Number of Pins 20
Material - Core Ferrite
Technical
Packaging Tape & Reel (TR)
Tolerance 10%
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Composition Wirewound
Shielding Shielded
Depth 21mm
Inductance 35 μH
Test Frequency 100kHz
Max DC Current 9.3A
Frequency - Self Resonant 2MHz
Current - Saturation 9.3A
DC Resistance (DCR) - Parallel 7mOhm
Dimensions
Height 14.2mm
Height Seated (Max) 14.1986mm
Length 21.4884mm
Width 21.0058mm
Compliance
RoHS Status RoHS Compliant
