B82479G1154M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED fixed air core inductor 150C 100kHz 293mOhm 150muH
PDF
/
Inventory: 4376
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Weight 3.000003g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, Blister, 13 Inch
Shielding Shielded
Number of Functions 1
Depth 15.24mm
Construction Rectangular
Current Rating 1.3A
Military Standard Not
Inductance 150 μH
Test Frequency 100kHz
Max DC Current 1.3A
Frequency - Self Resonant 100kHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 2.1A
Case/Size Code 7360
DC Resistance (DCR) - Parallel 293mOhm
Inductance-Nom (L) 150 μH
DC Current 1.3A
Dimensions
Height 7.25mm
Height Seated (Max) 7.112mm
Length 18.5mm
Width 15.24mm
Compliance
RoHS Status RoHS Compliant
