B82472G6102M

EPCOS
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant ONE SURFACE DUAL ENDED Fixed Inductor -55C 100kHz 15mOhm 1μH
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $0.997433
≥1 USD $0.997433
≥10 USD $0.940982
≥100 USD $0.887713
≥500 USD $0.837464
≥1000 USD $0.790069
Inventory: 1635
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 7.3mm
Length 7.2898mm
Height Seated (Max) 3.5052mm
Height 3.3mm

Technical

DC Current 3.6A
Inductance-Nom (L) 1 μH
DC Resistance (DCR) - Parallel 15mOhm
Case/Size Code 2929
Current - Saturation 3.3A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 3.6A
Test Frequency 100kHz
Inductance 1 μH
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Military Standard Not
Current Rating 3.6A
Construction Rectangular
Depth 7.5mm
Number of Functions 1
Shielding Shielded
Packing Method TR, Blister, 13 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Packaging Digi-Reel?

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 1.500002g
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mount Surface Mount
