B82144F2222K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant 8504.50.80.00 RF INDUCTOR fixed air core inductor 125C 140MHz 55mOhm 2.2muH
PDF
/
Inventory: 8827
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case Axial
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Packaging Tape & Reel (TR)
Tolerance 10%
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 14 INCH
Shielding Unshielded
Number of Functions 1
Construction Tubular
Current Rating 3.65A
Lead Diameter 0.8 mm
Inductance 2.2 μH
Test Frequency 1MHz
Frequency - Self Resonant 140MHz
Inductor Application RF INDUCTOR
Quality Factor-Min (at L-nom) 60
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 6A
DC Resistance (DCR) - Parallel 55mOhm
Inductance-Nom (L) 2.2 μH
Special Feature FLAME PROOF, Q FACTOR IS MEASURED AT 2.52 MHZ, INDUCTANCE IS MEASURED AT 1 mA
Dimensions
Length 9.1948mm
Compliance
RoHS Status RoHS Compliant
