UP0.4C-3R3-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
UNI-PAC? 0.4C Nonstandard 0.260Lx0.175W 6.60mmx4.45mm 3.3muH
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.120507
≥1 USD $1.120507
Inventory: 4452
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 907.18474mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series UNI-PAC? 0.4C
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.89A
Shielding Unshielded
Depth 4.45mm
Current Rating 1.89A
Inductance 3.3μH
Test Frequency 100kHz
DC Resistance (DCR) 60mOhm Max
Max DC Current 1.89A
Inductance Frequency - Test 100kHz
Current - Saturation 2A
Dimensions
Height 2.92mm
Height Seated (Max) 0.115 2.92mm
Length 6.6mm
Width 4.445mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
