SD14-681-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SD Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 680muH
PDF
/
Inventory: 7873
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 453.59237mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SD
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 156mA
Shielding Shielded
Current Rating 156mA
Inductance 680μH
Test Frequency 100kHz
DC Resistance (DCR) 10.3Ohm
Max DC Current 142mA
Inductance Frequency - Test 100kHz
Current - Saturation 142mA
Dimensions
Height 1.45mm
Height Seated (Max) 0.057 1.45mm
Length 5.1816mm
Width 5.1816mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
