SD10-6R2-R image
Favorite
SD10-6R2-R image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SD Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 6.2muH
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.537406
≥1 USD $1.537406
≥200 USD $0.594744
≥500 USD $0.57505
≥1000 USD $0.564547
Inventory: 5806
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Weight 907.18474mg
Material - Core Ferrite

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SD
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 940mA
Shielding Shielded
Depth 5.2mm
Current Rating 940mA
Military Standard Not
Inductance 6.2μH
Test Frequency 100kHz
DC Resistance (DCR) 218mOhm
Max DC Current 920mA
Inductance Frequency - Test 100kHz
Current - Saturation 920mA
DC Current 940mA

Dimensions

Height 1mm
Height Seated (Max) 0.039 1.00mm
Length 5.1816mm
Width 5.1816mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
