HCM1A1104-220-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 22UH 3.2A 65MOHM SMD
PDF
/
Buying Options
Total Price: USD $2.31
Unit Price: USD $2.31037
≥1 USD $2.31037
≥10 USD $2.179598
≥100 USD $2.056225
≥500 USD $1.939832
≥1000 USD $1.830027
Inventory: 1098
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Iron Powder
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Series HCM1A
Size / Dimension 0.453Lx0.406W 11.50mmx10.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 3.2A
Shielding Shielded
Inductance 22μH
DC Resistance (DCR) 65mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 6A
Inductance Tolerance 20%
Dimensions
Height Seated (Max) 0.157 4.00mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
